7
The components of the Intellian i3/i3L/i4/i4P are designed as module
system so that it is suitable for simple installation on all types of
vessels.
System Components
Antenna Unit
The antenna of Intellian i3/i3L/i4/i4P is comprised of the following
components for optimum search and receiving satellite signal.
• Mechanical Unit – manipulates the antenna to receive the optimal
satellite signal regardless of the movement of the vessel.
• Control Unit – controls mechanical operation of the antenna.
• RF Unit – transmits the optimum satellite signal to the receiver.
• Radome – protects the antenna from the severe marine environment.
Installation
Figure 02 : Radome
