31
AZ : ###.# EL : ##.#
SIGNAL : ### ● [VL]
Monitoring Current Status
When powered on, ACU displays the status of the antenna.
The current status of the antenna is displayed as shown below.
1. The antenna is searching for satellite A. 5. Antenna position detail and signal strength are
displayed.
3. The antenna is unwrapping the cable.
2. The antenna is tracking satellite A.
4. The antenna is again tracking satellite A.
Press center soft key to display position detail.
SEARCH A: DTV101
ANTENNA IS UNWRAPPING
TRACKING A: DTV101
TRACKING A: DTV101
B:DTV119 SETUP
B:DTV119 SETUP
B:DTV119 SETUP
B:DTV119 SETUP
6. Press center soft key to display current GPS
information. Press center soft key to return
to main tracking mode.
###.##E ##.##N
