Figure 02 : Antenna Unit
System Components
Antenna Unit
The antenna of Intellian i6/i6P/i6PE is manufactured with the following
components for the optimum search and reception of the satellite signal.
Mechanical Unit – manipulates the antenna to receive the optimal satel-
lite signal regardless of the movement of the vessel.
• Control Unit – controls mechanical operation of the antenna.
• RF Unit – transmits the optimum satellite signal to the receiver.
• Radome – protects the antenna from the severe marine environ-
ment.
Installation
The components of the Intellian i6/i6P/i6PE have been designed to be
modular enabling simple installation on all types of vessels.
