Intellian i6 - i6;i6 P Technical Specifications; General and Environmental Specifications; Antenna System Performance

77
General
Approvals
CE – conforms to
FCC – veried to
EU Directive 89/336/EEC
CFR47:Part 15
Dimensions
Satellite antenna unit
Antenna dish diameter
Antenna control unit
70cm (27.5”) x 72cm(28.3”)
60cm(23.6”)
17.8cm(7”)x21.7cm(8.5”)x5.4cm(2.1”)
Weight
Satellite antenna unit
Antenna control unit
20kg (44 lbs)
1.2kg (2.6 lbs)
Environmental
Operating temperature range
Storage temperature range
Humidity limit
-25°C to +55°C (-13°F to +131°F)
-40°C to + 80°C (-40°F to + 176°F)
95% R.H
Power requirements 9~30 V DC
Power consumption Typ. 30W, Max. 50W
Antenna system performance
Frequency Ku-band (10.7 to 12.75 GHz)
Minimum EIRP 47 dBW
Azimuth range 680°
Elevation range +5° ~ +90°
Ship’s motion
Roll ±25°
Pitch ±15°
Roll and pitch
response rate
45° per second
Turn rate 45° per second
Appendix : i6/i6P Technical Specication
