Intellian Satellite TV Antenna Systems

CODE 101

CODE 102

CODE 103

CODE 104

CODE 105

CODE 106

CODE 107

CODE 108

CODE 109

CODE 110

RESULT

STATUS

Data communication between antenna and antenna control unit is

tested. If failed, check the RF cable.

AZ CW limit is tested.

If failed, check the limit sensors, motor and belt for AZ axis.

AZ CCW limit is tested.

If failed, check the limit sensors, motor and belt for AZ axis.

EL axis is tested.

If failed, check the limit sensors, motor and belt for EL axis.

Sub reector is tested.

If failed, check the sub reector.

LNB is tested.

If failed, check the LNB and control board.

Skew System is tested.

if failed, check the control board, skew motor, and skew sensor.

Antenna Input Power is tested.

If failed, check the RF cable.

ACU Power is tested.

If failed, check the ACU power cable and Input DC power.

IRD Power is test to IRD cable and IRD power.

• Test is passed.

- Test is skipped.

? Test is under processing.

Number refers to an error code

(••3••• -•••) 3 means error code 103.

CODE*
