Intellian i6P Installation And Operation User Guide

5
Built-in GPS
Intellian i6/i6P/i6PE has an embedded GPS, which allows for the system
to upload the GPS data automatically into the system for an even faster
and stable system.
Built-in automatic skew angle control system
The automatic skew control system allows Intellian i6P/i6PE to maintain
the optimal skew angle at all times and ensure maximum level of
satellite signal level.
Wide elevation angle
Intellian i6PE is primary designed for receiving satellite signal at polar
regions with its wide elevation angle design. With an extra pointing
angle, the i6PE can track satellite from -15° to +90° elevation.

Intellian i6P Specifications

Operating Environment

operating temperature range	-25°C to +55°C
storage temperature range	-40°C to +80°C
humidity limit	95% R.H

Antenna System Performance

frequency	Ku-band (10.7 to 12.75 GHz)
minimum EIRP	46 dBW
azimuth range	680°
elevation range	-5° to +90°
roll	±25°
pitch	±15°
roll and pitch response rate	45° per second
turn rate	45° per second

Power

power requirements	9~30 V DC
power consumption typical	30W
power consumption maximum	50W

Weight and Dimensions

satellite antenna unit dimensions	70 cm x 72 cm
antenna dish diameter	60 cm
antenna control unit dimensions	17.8 cm x 21.7 cm x 5.4 cm
satellite antenna unit weight	21 kg
antenna control unit weight	1.2 kg
