Intellian i6P Installation And Operation User Guide

62
Intellian Satellite TV Antenna Systems
Parameter Setting - To set antenna parameter values.
Scan Offset
Track Scale
Detect Level
WRS Level
Track Offset
Power Level
DiSEqC Level
Offset RH-LH
EL Offset
Use WRS
Offset
Difference
The scan offset is to offset the angle difference between the
black marker on the sub-reector and the optical sensor.
The track scale is to control the tracking speed while antenna
is tracking the satellite.
The detect level is to set the satellite signal detection level.
The WRS level is to set the WRS detection level.
The tracking offset is to offset the satellite signal tracking
level.
The power level is to distinguish the voltage between 13 V and 18 V.
The DiSEqC level is to distinguish 0KHz tone and 22KHz tone.
The offset RH-LH is to offset the signal difference between
RHCP and LHCP.
The EL offset is to offset the angle difference between the
mechanical elevation angle and actual elevation angle.
Use WRS is to determine whether the system uses WRS level
or not. “Use WRS” and “WRS Level” are pair functions.
Offset difference is to determine whether the system to uses
“Offset RH-LH” or not. “Offset Difference” and “Offset RH-LH”
are pair functions.

Intellian i6P Specifications

Operating Environment

operating temperature range	-25°C to +55°C
storage temperature range	-40°C to +80°C
humidity limit	95% R.H

Antenna System Performance

frequency	Ku-band (10.7 to 12.75 GHz)
minimum EIRP	46 dBW
azimuth range	680°
elevation range	-5° to +90°
roll	±25°
pitch	±15°
roll and pitch response rate	45° per second
turn rate	45° per second

Power

power requirements	9~30 V DC
power consumption typical	30W
power consumption maximum	50W

Weight and Dimensions

satellite antenna unit dimensions	70 cm x 72 cm
antenna dish diameter	60 cm
antenna control unit dimensions	17.8 cm x 21.7 cm x 5.4 cm
satellite antenna unit weight	21 kg
antenna control unit weight	1.2 kg
