Intellian i6P User Manual

67
- Edit Satellite Information: push the “Edit Satellite Information” button
to update the information after modifying values.
- Load Default: Push the “Load Default” button to select a regional
library le *.rif according to your region.
- Update Default: After loading a regional library le *.rif, push the
“Update Default” button to update the system.
- Diseqc: When the operation method of DiSEqC is selected to “Change
Band”, DiSEqC may be used for updating the local frequency and to
“Change Satellite”, for updating the target satellite.
- Dual Satellite Mode/ Triple Satellite Mode: Registers the target satellite.
• Pushing ‘Register for Sat A’ or ‘Register for Sat B’ button after
selecting the satellite in the list box makes it possible to register A or B
in Dual Satellite Mode.
• Pushing ‘Register for Sat A’ or ‘Register for Sat B’ or ‘Register for Sat
C’ button after selecting the satellite in the list box makes it possible to
register A or B or C in the Triple Satellite Mode.
• Transponder information consists of frequency, symbol and NID
(Network ID) of a transponder in tracking the satellite. There are four
groups of transponder information. ‘Vertical/RHCP’ is applied when
the IRD supplies 13V, and ‘Horizontal/LHCP’ is applied when the IRD
supplies 18V. ‘LOW’ is applied when DiSEqC signal is not detected from
IRD. ‘HIGH’ is applied when the DiSEqC signal is detected from the IRD.
After modifying information, press the ‘Edit Satellite Information’ button,
then new information is updated in the antenna.
- Pol & Band Control: The “Pol” controls 13V (Vertical/RHCP band) or 18V
(Horizontal/ LHCP band). The “Band” controls DiSEqC 0KHz tone (Low
band) and 22KHz tone (High band). After modifying information, press
‘Edit Satellite Information’ button, then new information is updated in
the antenna.
- Triple Satellite Mode: To select between Dual-Sat mode and Triple-Sat
mode, tick the ‘Triple Satellite Mode’ box at the bottom of the screen.

Intellian i6P Specifications

Operating Environment

operating temperature range	-25°C to +55°C
storage temperature range	-40°C to +80°C
humidity limit	95% R.H

Antenna System Performance

frequency	Ku-band (10.7 to 12.75 GHz)
minimum EIRP	46 dBW
azimuth range	680°
elevation range	-5° to +90°
roll	±25°
pitch	±15°
roll and pitch response rate	45° per second
turn rate	45° per second

Power

power requirements	9~30 V DC
power consumption typical	30W
power consumption maximum	50W

Weight and Dimensions

satellite antenna unit dimensions	70 cm x 72 cm
antenna dish diameter	60 cm
antenna control unit dimensions	17.8 cm x 21.7 cm x 5.4 cm
satellite antenna unit weight	21 kg
antenna control unit weight	1.2 kg
