v100 – Marine Satellite Communication System

150

Modem Rx

Modem Interface

(OpenAMIP)

iDirect INFINITI 5000

Antenna Control Unit

Internet / Email

OpenAMIP Protocol

• GPS

• Lock / Unlock

• TX Mute

• Auto Beam Switching

Integrated with iDirect INFINIT5000

• iDirect Modem interface through the OpenAMIP
