151

APPENDIX

Modem Interface

(OpenAMIP)

Modem Rx

iDirect X5

Router / Network Hub

Antenna Control Unit

Internet / Email

Integrated with iDirect X5

• iDirect Modem interface through OpenAMIP (Ethernet)

Modem Interface

(OpenAMIP)

OpenAMIP Protocol

• GPS

• Lock / Unlock

• TX Mute

• Auto Beam Switching
