V110 – Marine Satellite Communication System
System Cables
Before installing the system cables, you need to take the following
points into consideration.
All cables need to be well clamped and protected from physical
damage and exposure to heat and humility.
Cable with an acute bend is not allowed.
Where a cable passes through an exposed bulkhead or deck
head, a watertight gland or swan neck tube should be used.
RF Cables (Customer Furnished)
Due to the voltage losses across the length of the RF coaxes at L-Band,
Intellian recommends the following 75 ohm coax cable types for
standard system installations. For cable runs longer than 70 meter,
please consult Intellian Technologies.
Run Length Coaxial Cable Type
Up to 30 meters RG-6 or LMR-300-75
Up to 70 meters RG-11 or LMR-400-75
Up to 120 meters LMR-600-75
Figure 8. Recommended RF Cables
Gyro Compass / GPS Interface Cable (Customer Furnished)
Type Multi-conductor, Shielded
Number of wires 4 Conductors for Step-By-Step Gyro
5 Conductors for Synchro
2 Conductors for NMEA
Figure 9. Recommended Gyro/ GPS Cables
BUC Power Cable
Cable Length mm
2
per conductor
Up to 30m 1.25mm
2
Up to 50m 2mm
2
Up to 70m 2.5mm
2
Up to 100m 3.5mm
2
Figure 10. Recommended BUC Power Cables
Power Requirements
Intellian v110 has been designed to work on a vessel’s power supply
rated at 90-260 V AC.
