EMI-300
7-CHANNEL 2 X 150W MIXING AMPLIFIER
16. TAPE LINE INPUT SWITCH
Pressing this switch will activate the Tape line input of Line Inputs 1-5 (25). The physical connectors for the
Tape input channels are on the rear panel, with the level being controlled both by a rear panel stereo Line
Input Gain Control (26) and a front panel master Line Input Volume Control (Front Panel 4).
17. OUTPUT METER AND LIMITER LED
The six-segment LED meter indicates the signal levels being sent to AMP 1 and AMP 2. When the sixth
segment “LIMIT” LED is lit, it indicates that the signal is near clipping, and that the limiter circuitry has
engaged to prevent overload distortion.
