Interlogix DDV1016AM User Manual

2 / 52 P/N 146667999-1 (ML) • REV G • ISS 19AUG19
5
6
7
8
9
Cable inlet (1)
Remove
2
for
ST400 ( )
Cable
gutter ( )3
9 1
8 2
7 3
6 45
1 2 3 5 7 8 9
4
D
4
C
4
B
4
A
6
A
6
B
6
C
6
D
240 cm
(7 ft. 10 in.)
90 cm
(2 ft. 11 in.)
(1) (2)
1A
1B
9A
9B2B-3B 7B-8B
5B
4 6
1A
1B
2B
3B
4
9B
8B
7B
6
9A
5B
(3) 5 curtains
8 m range
(4) 7 curtains
8 m range
(1)
(2)
(5) 5 curtains
16 m range
(6) 7 curtains
16 m range
(7) 9 curtains
16 m range
7
Walk test (3)
8
Day/night (4)
47K
47K
12K
+12 V
SW1-3
On
Polarity: Active high (1)
7
Walk test (3)
8
Day/night (4)
47K
47K
12K
+12 V
SW1-3
Off
Polarity: Active low (2)
Walk test On =
Walk test Off =
Night (armed) =
Day (disarmed) =
Pin 7 to GND
Pin 7 to +12 V or floating
Pin 8 to GND
Pin 8 to +12 V or floating
Walk test On =
Walk test Off =
Night (armed) =
Day (disarmed) =
Pin 7 to +12 V
Pin 7 to GND or floating
Pin 8 to +12 V
Pin 8 to GND or floating
