Adjusting the Label Mark Sensor
The label mark sensor detects the mark on the back of continuous media stock. The
printer uses the output to determine the start of print. The label mark sensor is behind
the platen roller and near the inboard edge of the printer.
To adjust the label mark sensor
1. Remove the media cover and locate the label mark sensor.
2. Use your index finger to slide the label mark sensor to the correct position for your
media. You can position the label mark sensor anywhere from the inboard edge of
the printer to the center of the paper path.
3. Enable mark printing with PrintSet, your third-party software, or IPL commands.
For help, see PrintSet online help, your third-party documentation, or the IPL
Programming Reference Manual.
4. Print a few labels or press Feed/Pause two times to make sure that the label mark
sensor is detecting the black mark on the media.
5. Replace the media cover.
