Intermec PM43 User Manual

Appendix B — Default Settings
130 PM23c, PM43, and PM43c Mid-Range Printer User Manual
Wireless 802.11 General Settings
This section describes the 802.11 general settings. To view these
settings:
• From the printer Main Menu, select Settings > Communications
> Wireless 802.11 > General.
• From the printer web page, click the Configure tab,
Communications > Wireless 802.11.
Default Router Specifies the IP address of a router that
is used when a device sends a packet to
another subnet or to an unknown
destination.
0.0.0.0
DHCP Response Specifies if the printer receives DHCP
responses by broadcast or unicast.
Broadcast
(IPv6) IP
Assignment
Method
Specifies how the printer obtains an IP
address (for IPv6 networks).
Automatic
(IPv6) IP Address Specifies the unique network-level
address that is assigned to each device
in a TCP/IP network (IPv6).
Automatic
Ethernet Settings (Continued)
Setting Description Default
Wireless 802.11 General Settings
Setting Description Default
Network
Name (SSID)
Defines the wireless network. To
communicate, all access points and wireless
devices must have the same network name,
which is case-sensitive.
INTERMEC
Network
Type
Selects the radio behavior of the printer. Ad
Hoc mode allows the printer to communicate
directly with another printer. Infrastructure
mode allows the printer to communicate
through an access point.
Infrastructure
Roaming Controls the roaming inclination of the
printer. The higher the level, the less inclined
the printer is to switch access points based on
the printer received signal strength (RSSI).
Off

Intermec PM43 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	108 mm
Ethernet LAN	Yes
Optional connectivity	Bluetooth, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Certification	RoHS, CE (EN55022 Class A), FCC Class A, UL/cUL, D Mark and CCC
Internal memory	128 MB
Built-in barcodes	1D, 2D
Image formats supported	BMP, GIF, PCX, PNG
Page description languages	DP, DPL, IPL, XML, ZPL II
Display	LCD
Control type	Touch
Product color	Gray
PC connection	RS-232
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	45 - 65 Hz
Power consumption (standby)	9 W
Media thickness	3 - 10.4 mm
Maximum label width	114 mm
Maximum roll diameter	80 mm
Languages support	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, KOR, POR, RUS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	483.54 mm
Width	284.2 mm
Height	294.61 mm
Weight	15820 g
