Intermec PM43 User Manual

Chapter 4 — Configure the Printer
PM23c, PM43, and PM43c Mid-Range Printer User Manual 75
About Printer Profiles
After you change printer default settings to meet your needs, you can
save those settings as a printer profile. The printer supports multiple
profiles that you can save and load at any time. For example, you can
create one profile to use when you are printing on continuous label
stock, and a different profile to use when you are printing on label
stock with gaps. Printer profiles are only supported from the Main
Menu on the full touch printer.
The following printer settings are not saved in a profile:
• IP address for either IPv4 or IPv6 networks
• Media calibration settings for the label stop sensor
• Remote port or remote host values for a remote computer
accessing the printer through raw TCP
Save a Printer Profile from the Main Menu
Use this procedure to save the current settings as a printer profile.
1 From the Ready screen, press the Main Menu button. The Main
Menu appears.
2 Select Tools > Profiles. The Profiles menu appears.
3 Select Save. The Save Profile menu appears.
4 Select the Filename text box and type a name for the profile. The
profiles can have up to sixteen characters.

Intermec PM43 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	108 mm
Ethernet LAN	Yes
Optional connectivity	Bluetooth, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Certification	RoHS, CE (EN55022 Class A), FCC Class A, UL/cUL, D Mark and CCC
Internal memory	128 MB
Built-in barcodes	1D, 2D
Image formats supported	BMP, GIF, PCX, PNG
Page description languages	DP, DPL, IPL, XML, ZPL II
Display	LCD
Control type	Touch
Product color	Gray
PC connection	RS-232
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	45 - 65 Hz
Power consumption (standby)	9 W
Media thickness	3 - 10.4 mm
Maximum label width	114 mm
Maximum roll diameter	80 mm
Languages support	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, KOR, POR, RUS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	483.54 mm
Width	284.2 mm
Height	294.61 mm
Weight	15820 g
