Chapter 3 — Connect the Printer
46 PM23c, PM43, and PM43c Mid-Range Printer User Manual
About Printer Drivers
Before you can use the printer with Microsoft Windows printing
applications, you need to install printer driver software on the PC.
Drivers enable the printer to communicate with your PC and with
software applications such as Intermec PrintSet 5.
Install Printer Drivers
Use InterDriver to install printer driver software on your PC.
InterDriver is available from the Intermec website. Follow this
procedure to download InterDriver from the Intermec website and
install the drivers.
1 Open a web browser and go to www.intermec.com.
2 Select Support > Downloads.
3 Select these items:
a In the Product Category list, select Printers.
b In the Product Family list, select Printer Software.
c In the Product list, select InterDriver and then click Submit.
4 In the InterDriver downloads page, click InterDriver - Windows
ver. X.XX. If a Security Warning dialog box appears, click Run.
5 Select I accept the terms in the license agreement and then click
Next twice.
6 Clear the Read installation instructions check box, and then click
Finish.
7 Navigate to C:\Intermec\InterDriver7 and double-click
DriverWizard. If a User Account control dialog box appears, click
Yes to continue.
8 Make sure that Install printer drivers is selected, and then click
Next.
Note: Although Windows may auto-detect the printer when you
connect it to a PC through a USB port, you must still install printer
drivers on the PC for correct printer operation.

Intermec PM43 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	108 mm
Ethernet LAN	Yes
Optional connectivity	Bluetooth, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Certification	RoHS, CE (EN55022 Class A), FCC Class A, UL/cUL, D Mark and CCC
Internal memory	128 MB
Built-in barcodes	1D, 2D
Image formats supported	BMP, GIF, PCX, PNG
Page description languages	DP, DPL, IPL, XML, ZPL II
Display	LCD
Control type	Touch
Product color	Gray
PC connection	RS-232
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	45 - 65 Hz
Power consumption (standby)	9 W
Media thickness	3 - 10.4 mm
Maximum label width	114 mm
Maximum roll diameter	80 mm
Languages support	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, KOR, POR, RUS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	483.54 mm
Width	284.2 mm
Height	294.61 mm
Weight	15820 g
