12
Interwrite
TM
Board Getting Started
Attaching the Floor Stand Mounting
Brackets to the Interwrite Board
After you have assembled the floor stand (instruc-
tions on page 44), you will attach the Mounting
Brackets that came with the floor stand to the back
of the Interwrite Board.
1 Attach the Mounting
Brackets to the back of the
Interwrite Board frame. The
Slide Slot is oriented toward
the top of the Interwrite
Board, the Ratchet Slots are
toward the bottom, and the
short side of the bracket
points inward toward the
center of the board.
2 Line up the holes in the bracket
with the Brass Inserts on the
frame. Use the two small screws
provided to attach the bracket.
Slide
Slot
Ratchet
Slot
Mounting
Brackets
Tools Required:
Phillips
screwdriver
Interwrite Board
Brass Insert
Mounting
Bracket
Small
Screw
To Next Page
