Operating Manual for Digital Sound Processor (DSP) V3.0
WWW.INTREND-AV.RU
6
A
/D Technical Indicators:
Sampling rate: 48kHz
THD+N:≤0.001%@4dBu（A-weighting）
Dynamic range: 110dB
Audio format: 24Bit MSB TDM
1.3 Audio Output Section
Phase 1 of analog output section refers to D/A converter (DAC). DSP adopts advanced 24-
bit 256X sampling converter. Just like A/D converter, it also uses multi-bit architecture for
broader dynamic range; in the meantime, it is also equipped with excellent distortion just like
regular digital unit analog converter. Unit gain (0dB) is set via volume control, and the analog
output section is corrected as +4dBu with 20dB headroom. That is to say, 0dBFS digital signal is
equivalent to +24dBu output signal. If other signal levels are required, you may change the
volume to achieve it.
D/A Technical Indicators:
Sampling rate: 48kHz
THD+N:≤0.001%@4dBu（A-weighting）
Dynamic range (A-weighted): 112dB
Audio format: 24Bit MSB TDM
