Set-up
5.Guidethekeythroughthesmallbrackethole.Thekey
isattachedtothebedbracketwithalanyard.
6.Turnandlockthekeyonceitisfullyinserted.Repeat
ontheotherside,thentheoppositebedend,securing
bothmountingpointsoneachboard.
Somemodelsonlyhaveoneconnection.
7.Attachthecablesfromthefootendboardtothebed
cables(ACPcableandpendantcoupling).Tightenthe
nut*.
*ACPbedonly.
1153410-Q
35
