Invacare Carroll CS Series User Manual

Invacare®CarrollCSSeries™
DANGER!
RiskofDeath,InjuryorDamage
Pendantmalfunctionmaycauseinjuryordamage.
–Unplugbedfromelectricaloutletandcontact
qualiedtechnicianorInvacareforrepairifany
malfunctionisdetected.
RaisingandLowering
C
A
E
D
B
F
C
A
E
D
B
F
G
H
B
G
H
A
D
C
F
E
EntireBed
1.Toraisetheentirebed,presstheBedUpbuttonA.
2.Tolowertheentirebed,presstheBedDownbuttonB.
HeadandFootSections
1.Toraisetheheadsection,presstheHeadUpbuttonC.
2.Tolowertheheadsection,presstheHeadDownbutton
D.
3.Toraisethefootsection,presstheFootUpbuttonE.
4.Tolowerthefootsection,presstheFootDownbutton
F.
5.Toraisetheheadandfootsectionssimultaneously,
presstheHeadandFootUpbuttonG.
6.Tolowertheheadandfootsectionssimultaneously,
presstheHeadandFootDownbuttonH.
5.2PendantStorageandLocation
Beforeworkingonanyelectricalpart,suchasthe
9-pinpendantcoupling,ensurethemainpowerto
thebedisdisconnected.
Afterdisconnectingthepower,sequentiallydepress
the‘Up’and‘Down’buttonsonthehandpendant
atleast20timestodispelanyremainingcharge.
Ensurethehandpendantisnotlocked-outwhen
performingthisfunction.
38
1153410-Q
