1.Tooperatethelockoutfunction,eithermovetheHI/LO
switchAtoOFForpressthelockbuttonA.
2.Whenthelockoutfunctionisnotactivated,thearrow
buttonsBcanbeusedtoraiseandlowerthebed.
6.6Optional39Inchand42InchWideDecks
Thefollowingbedoptionsarenotcompatiblewith
the39inchor42inchwidebeddeck:68inchrail.
TheCSbedisavailablewithwiderdecksforresident
comfort.Both39inchwidedeckand42inchwidedecks
arefactoryinstalledoptions.
39inchor42
inchNominal
6.7AdjustableWidthBedModelCS9FX600
Thefollowingbedoptionsarenotcompatiblewith
theCS9FX600:68inchrail.
6.7.1AdjustingtheCS9FX600BedWidth
Alleightadjustabledeckwingsmustbeadjustedto
thesamewidth.Ensuretheappropriatebedand
headboardsettingsareusedasdescribedinthis
procedure.
TheCS9FX600haseightadjustabledeckwingswhichcanbe
adjustedto36in,39inor42in.Thelocationsofthewings
andadjustmentknobsareshowninthegurebelow.
50
1153410-Q
