3-wheel version:
• Slacken brake cable (see chapter entitled
"Replacing brake cable" on page 37).
• Disconnect the brake cable at the wheel (1).
• Remove screws (3) on spacer (2).
• Remove screws (6) on shock absorber (5).
• Loosen axle bolts (4) simultaneously on both
sides.
• Pull front axle slowly out.
4-wheel version:
• Slacken both brake cables.
• Disconnect brake cable at affected wheel.
• Loosen wheel bolt.
• Pull wheel and brake off shaft.
• Pull brake out of brake drum.
• Replace brake lining or complete brake.
