Invacare®Perfecto₂™OxygenConcentrator
5Maintenance
5.1CleaningtheCabinetFilter
DANGER!
–Topreventelectricalshock,ALWAYSdisconnectconcentratorfromelectricaloutletbeforeservicing.
Ataminimum,preventivemaintenanceMUSTbeperformedaccordingtothemaintenancerecordguidelines.Inplaceswithhighdustor
sootlevels,maintenancemayneedtobeperformedmoreoften.
Refertorecyclinginformationfollowinglocalgoverningordinancesandrecyclingplansregardingdisposaloftheconcentratoror
components.
CAUTION!
RiskofDamage
Toavoiddamagetotheinternalcomponentsoftheunit:
–DONOToperatetheconcentratorwithoutthefilterinstalledorwithadirtyfilter.
Thereisonecabinetfilterlocatedonthebackofthecabinet.
1.RemovetheairscoopAfrombackofunit.
2.RemovethefilteraccesspanelBbypressingdownoncentertabCandpullingpanelout.
3.RemovecabinetfilterDfromfilteraccesspanelandcleanasneeded.
Environmentalconditionsthatmayrequiremorefrequentinspectionandcleaningofthefiltersincludebutarenotlimitedto:
highdust,airpollutants,etc.
4.Cleanthecabinetfilterwithavacuumcleanerorwashwithamildliquiddishdetergentandwater,rinsethoroughly.
5.Thoroughlydrythefilterandinspectfromfraying,crumbling,tearsandholes.Replacefilterifanydamageisfound.
6.Reinstallcabinetfilterontofilteraccesspanel
7.Reinstallfilteraccesspanelintounit.
8.Reinstallairscoopontobackofunit.
5.2CheckingtheOutletHEPAFilter
TheoutletHEPAfiltercanbecheckedduringpreventivemaintenanceorbetweenpatientsbyperformingthefollowingprocedure.
1.TurntheconcentratorOn(I)andadjusttheflowmetertothemaximumflowrateoftheunit.
2.Observetheflowmeter'sflowindicatorwhileconnectinga15.2m(50ft)cannulatubetotheoutletbarboftheconcentrator(notshown).
3.Iftheflowindicatorfluctuates,theoutletHEPAfiltermayneedreplacement.Referto9.1Troubleshooting,page48
12
1154245-F-02

Invacare Perfecto2 IRC5PO2AW Specifications

General

Flow Rate	0.5 to 5 LPM
Warranty	3 years limited
Operating Environment	10°C to 35°C; up to 95% relative humidity
Power Requirements	120 VAC, 60 Hz
Sound Level	≤45 dB(A)
Dimensions	23 in (H) x 13 in (W) x 12 in (D) (58.4 cm (H) x 33 cm (W) x 30.5 cm (D))
