Invacare®Perfecto₂™OxygenConcentrator
6.2ReplacingCompressorAssembly
6.2.1ReplacingCompressorAssemblyBeforeSeptember2015
DANGER!
RiskofDeath,Injury,orDamage
Topreventelectricalshock
–ALWAYSdisconnectconcentratorfromelectricaloutletbeforeservicing.
Refertorecyclinginformationfollowinglocalgoverningordinancesandrecyclingplansregardingdisposaloftheconcentratoror
components.
IRC5PO2AW
PEvalvenotshown. PEvalvenotshown.
IRC5PO2VAW
PEvalvenotshown. FilterandPEvalvenotshown.
1.TurnpowerOff(O)andunplugtheunit.
2.Removethecabinet.Referto6.1RemovingCabinet,page17.
3.CutthetiewrapAthatsecurestheintakehoseBtothecompressorassemblyC.
4.Disconnectintakehosefromcompressorassembly.
5.Removecompressorwiresfromwireclampsortie-wraps(notshown).
6.Disconnectcompressorconnectorfromthemainharnessconnector(notshown).
7.DisconnectcapacitorwiresDfromthetopofthecapacitorE.
181154245-F-02

Invacare Perfecto2 IRC5PO2AW Specifications

General

Flow Rate	0.5 to 5 LPM
Warranty	3 years limited
Operating Environment	10°C to 35°C; up to 95% relative humidity
Power Requirements	120 VAC, 60 Hz
Sound Level	≤45 dB(A)
Dimensions	23 in (H) x 13 in (W) x 12 in (D) (58.4 cm (H) x 33 cm (W) x 30.5 cm (D))
