Version 1.00 | Optidrive ODE-3 User Guide | 33www.invertekdrives.com
8.4. Modbus Register Map
Register
Number
Par.
Type
Supported
Function Codes
Function
Range Explanation
03 06 16
Low Byte High Byte
1 - R/W
✔ ✔ ✔
Drive Control Command 0..3 16 Bit Word.
Bit 0: Low = Stop, High = Run Enable
Bit 1: Low = Decel Ramp 1 (P-04),
High = Decel Ramp 2 (P-24)
Bit 2: Low = No Function, High = Fault Reset
Bit 3: Low – No Function, High = Coast Stop Request
2 - R/W
✔ ✔ ✔
Modbus Speed
reference setpoint
0..5000 Setpoint frequency x10, e.g. 100 = 10.0Hz
4 - R/W
✔ ✔ ✔
Acceleration and
Deceleration Time
0..60000
Ramp time in seconds x 100, e.g. 250 = 2.5 seconds
6 - R
✔
Error code Drive status
Low Byte = Drive Error Code, see section 10.1. Fault
Code Messages
High Byte = Drive Status as follows:
0: Drive Stopped
1: Drive Running
2: Drive Tripped
7 R
✔
Output Motor Frequency
0..20000
Output frequency in Hz x10, e.g. 100 = 10.0Hz
8 R
✔
Output Motor Current 0..480
Output Motor Current in Amps x10, e.g. 10 = 1.0 Amps
11 - R
✔
Digital input status 0..15 Indicates the status of the 4 digital inputs
Lowest Bit = 1 Input 1
20
P00-01 R
✔
Analog Input 1 value 0..1000 Analog input % of full scale x10, e.g. 1000 = 100%
21 P00-02 R
✔
Analog Input 2 value 0..1000 Analog input % of full scale x10, e.g. 1000 = 100%
22 P00-03 R
✔
Speed Reference Value 0..1000
Displays the setpoint frequency x10, e.g. 100 = 10.0Hz
23 P00-08 R
✔
DC bus voltage 0..1000 DC Bus Voltage in Volts
24 P00-09 R
✔
Drive temperature 0..100 Drive heatsink temperature in °C
All user configurable parameters are accessible as Holding Registers, and can be Read from or Written to using the appropriate Modbus
command. The Register number for each parameter P-04 to P-60 is defined as 128 + Parameter number, e.g. for parameter P-15, the register
number is 128 + 15 = 143. Internal scaling is used on some parameters, for further details please contact your Invertek Drives Sales Partner.
