Optidrive P2 Advanced User Guide Rev 2.00
4
www.invertekdrives.com
Optidrive P2 Parameter Set Overview
1
1. Optidrive P2 Parameter Set Overview
1.1. About this section
This document provides a list of the available parameters, and a description of their respective functions, for the Optidrive P2.
1.2. Parameter Structure Overview
The parameter set is arranged in Groups according to the following structure
Parameter Group
Range
Name
Access Level
Access Type
Group 0
P0-01 to P0-50
Basic Monitoring
Extended
Read Only
P0-51 to P0-80
Advanced Monitoring
Advanced
Read Only
Group 1
P1-01 to P1-14
Quick Start Menu
Basic
Read / Write
Group 2
P2-01 to P2-40
Extended Parameters
Extended
Read / Write
Group 3
P3-01 to P3-12
PID Controller
Extended
Read / Write
Group 4
P4-01 to P4-12
Motor Control
Extended
Read / Write
Group 5
P5-01 to P5-10
Communications
Extended
Read / Write
Group 6
P6-01 to P6-30
Advanced Functions
Advanced
Read / Write
Group 7
P7-01 to P7-10
Advanced Motor Data
Advanced
Read / Write
Group 8
P8-01 to P8-10
Application Specific Group
Advanced
Read / Write
Group 9
P9-01 to P9-30
Programmable Logic
Advanced
Read / Write
Access to all parameter groups is controlled by setting P1-14 as follows
P1-14 = P2-40 (Factory setting: 101) Allows Extended Parameter Access
P1-14 = P6-30 (Factory Setting: 201) Allows Advanced Parameter Access
