Optidrive P2 Advanced User Guide Revision 2.00
www.invertekdrives.com
71
General Technical and Performance Data
8
8. General Technical and Performance Data
8.1. Electrical Data
8.1.1. Mains Supply Details
Supply Voltage Range
230 Volt Units – 200 – 240 Volt +10% / -10%
400 Volt Units – 380 – 480 Volt +10% / -10%
600 Volt Units – 500 – 600 Volt +10% / -10%
Supply Frequency
48 – 62Hz
Inrush Current
< rated input current
Power Up Cycles
>120x /hr, evenly spaced
Single Phase Operation
Three phase drives can be operated from a single phase supply with 50% derating of the maximum output
current
8.1.2. Motor Control
Output Frequency Range
0 to 500Hz in 0.1 Hz steps
High Frequency Option Available, up to 2000Hz depending on model rating. Max Output Frequency = Max
Switching Frequency / 16.
Output Voltage Range
0 to Supply Voltage
Speed Regulation
Open Loop < 2% motor rated speed
Torque Control
0 – 200% of rated torque, + / -5% accuracy, Response time <10ms
Effective Switching Frequency
Refer to section 2.1
Acceleration Time
Four independent acceleration ramps
0 – 600 seconds, 0.01s resolution (Frame 2 & 3)
0 – 6000 seconds, 0.1s resolution (Frame 4 & above)
Deceleration Time
Four individual deceleration ramps
0 – 600 seconds, 0.01s resolution (Frame 2 & 3)
0 – 6000 seconds, 0.1s resolution (Frame 4 & above)
8.1.3. Overload Capacity
Overload Capacity
150% of rated current for 60 seconds, repeat cycle every 10 minutes.
200% / 4 seconds
8.2. Input Output Current Ratings
8.2.1. 230V Input
Frame
Size
Supply
Voltage
Power
Rating
(kW)
Input
Current
(A)
iTHD
(%)
AC
Line
Choke
Input
Current
(A)
iTHD
(%)
Output
Current
(A)
2
230V, 1ph
0.75
8.6
125
OPT-2-L1016-20
4.9
4.3
1.5
12.9
105.8
OPT-2-L1016-20
13.5
7.0
2.2
19.2
97
OPT-2-L1025-20
17.3
10.5
230V, 3ph
0.75
5.7
177.8
OPT-2-L3006-20
4.0
53.6
4.3
1.5
10.5
155.0
OPT-2-L3006-20
6.2
39.4
7.0
2.2
13.2
147.2
OPT-2-L3010-20
9.2
33.1
10.5
3
230V, 3ph
4.0
20.9
115.5
OPT-2-L3036-20
16.0
37.0
18
5.5
26.4
102.7
OPT-2-L3036-20
21.4
33.1
24
4
230V, 3ph
5.5
26.9
117
OPT-2-L3036-20
21.5
33.1
24
7.5
33.3
108
OPT-2-L3036-20
26.9
35.2
30
11
50.1
99.1
OPT-2-L3050-20
40.3
27.6
46
5
230V, 3ph
15
63.9
88
OPT-2-L3090-20
54.2
32.4
61
18.5
74.0
84.8
OPT-2-L3090-20
64
32.4
72
6
230V, 3ph
22
99.1
93.7
OPT-2-L3090-20
86.3
53.6
90
30
121.0
88.8
OPT-2-L3200-00
102.9
47.3
110
37
159.7
77.2
OPT-2-L3200-00
138.3
43.6
150
45
187.5
72.6
OPT-2-L3200-00
164.2
37
180
7
230V, 3ph
55
206.5
57.5
OPT-2-L3200-00
188.6
43.6
202
75
246.3
50.5
OPT-2-L3300-00
230.8
39.4
248
The data above is provided to show typical values. Results measured at the point of installation may vary according to the installation site and
load conditions Test results are measured under the following conditions :-
 230 Volt RMS AC Supply Voltage
 Operating IE2 motor with matching power rating according to the drive
 Operated at full rated output current capacity
