General Technical and Performance Data
8
8.5. Earth Leakage Current (Touch Current)
The Optidrive P2 and HVAC (ODP-2 and ODV-2) product range have been designed and tested to comply with the limits defined in EN 61800-5-
1: 2007. The test techniques used are as defined in EN 60990:2000.
As stated in the standard 61800-5-1:2007, 5.2.3.5 the motor does not have to be loaded, however, the motor type, cable type and length can
have a significant impact on the results. For the purpose of testing and test repeatability Invertek use the following motor:-
Manufacture:
SEW
Model:
DT90L4/ES1T
Type:
Induction motor
Pole:
4
Cable:
1.5m, 2.5mm
2
, Type - YY
Frame
Size
Typical Supply Conditions
Maximum Supply Conditions
Supply Voltage
I
Touch
(mA)
Supply Voltage
I
Touch
(mA)
2
1ph 230V 50Hz
2.49
1ph 240V +10% 60Hz
3.28
3ph 230V 50Hz
1.73
3ph 240V +10% 60Hz
2.73
3ph 400V 50Hz
4.65
3ph 480V +10% 60Hz
7.37
3
3ph 230V 50Hz
0.93
3ph 240V +10% 60Hz
1.34
3ph 400V 50Hz
1.55
3ph 480V +10% 60Hz
2.45
4
3ph 230Vac 50Hz
1.42
3ph 240V +10% 60Hz
2.24
3ph 400Vac 50Hz
2.47
3ph 480V +10% 60Hz
3.90
5
3ph 230Vac 50Hz
0.28
3ph 240V +10% 60Hz
0.44
3ph 400Vac 50Hz
0.49
3ph 480V +10% 60Hz
0.77
6
3ph 230Vac 50Hz
1.54
3ph 240V +10% 60Hz
2.43
3ph 400Vac 50Hz
2.68
3ph 480V +10% 60Hz
4.23
7
3ph 230Vac 50Hz
2.74
3ph 240V +10% 60Hz
4.33
3ph 400Vac 50Hz
4.75
3ph 480V +10% 60Hz
7.51
NOTE
The Touch Current value is based on:-
 Normal operating conditions, i.e. all phases balanced and connected correctly with the motor running
 Drive fitted with integrated EMC filter
