8.10.5. Over Current Trip Level
The following table shows the peak over current trip levels applicable to each model.
Frame Size
Voltage
kW
O-I Trip Level (Default P1-08)
H O-I Trip Level
2
230
0.75
14A
34.3A
1.5
20A
34.3A
2.2
30A
34.3A
400
0.75
7A
34.3A
1.5
12A
34.3A
2.2
17A
34.3A
4
27A
34.3A
600
0.75
7A
34.3A
1.5
10A
34.3A
2.2
14A
34.3A
4
17A
34.3A
5.5
26A
34.3A
3
230
4
55A
64A
5.5
70A
70A
400
5.5
45A
64A
7.5
55A
64A
11
70A
70A
600
7.5
45A
70A
11
55A
70A
15
70A
70A
4
230
5.5
70A
148A
7.5
85A
148A
11
120A
148A
400
11
70A
148A
15
90A
148A
18.5
110A
148A
22
120A
148A
600
15
90A
148A
18.5
100A
148A
22
110A
148A
30
120A
148A
5
230
15
180A
258A
18.5
180A
258A
400
30
180A
258A
37
180A
258A
600
37
180A
258A
45
180A
258A
6
230
22
225A
258A
30
320A
381A
37
425A
516A
45
450A
516A
400
45
225A
258A
55
320A
381A
75
425A
516A
90
450A
516A
600
55
225A
258A
75
320A
381A
90
425A
516A
110
450A
516A
7
230
55
570A
767A
75
650A
767A
90
700A
767A
400
110
570A
767A
132
650A
767A
160
700A
767A
8
400
200
1000A
1500A
250
1000A
1500A
8.11. Under / Over Voltage Trip Levels
The following levels are not user adjustable, and define the operating voltage levels of the drive and brake chopper circuit.
Drive Rated Supply
Voltage
DC Bus Voltage Level (Volts DC)
Brake Chopper On
Brake Chopper Off
Under Voltage Trip
Minimum Operating
Over Voltage Trip
200 – 240 Volts AC
390
378
160
239
418
380 – 480 Volts AC
780
756
320
474
835
480 – 525 Volts AC
890
862
360
540
930
500 – 600 Volts AC
975
945
400
598
1020
