7.2. Keypad mode (P1-12 = 1 or 2)
P2-01
Digital input 1 (T2)
Digital input 2 (T3)
Digital input 3 (T4)
Bipolar analog input (T6)
0
Open: Stop (disable)
Closed: Run (enable)
Closed : remote UP push-button
Closed : remote DOWN push-button
No Function
When stopped, closing inputs 2 & 3 simultaneously starts the drive
1
Open: Stop (disable)
Closed: Run (enable)
Closed : remote UP push-button
External trip input :
Open: Trip,
Closed: No Trip
Closed : remote DOWN push-button
2
Open: Stop (disable)
Closed: Run (enable)
Closed : remote UP push-button
Open: Digital (Keypad) Speed ref
Closed: Preset Speed 1
Open : Forward
Closed : Reverse
3..9, 13,
14 & 16
Open: Stop (disable)
Closed: Run (enable)
Closed : remote UP push-button
Closed : remote DOWN push-button
Open : Forward
Closed : Reverse
When stopped, closing inputs 2 & 3 simultaneously starts the drive
10
Open: Stop (disable)
Closed: Run (enable)
Open : Digital (Keypad) Speed ref
Closed : Bipolar analog speed ref
External trip input :
Open: Trip,
Closed: No Trip
Bipolar analog input
11
Open: Stop (disable)
Closed: Run (enable)
Open : Digital (Keypad) Speed ref
Closed : Preset speed 1
External trip input :
Open: Trip,
Closed: No Trip
Open : Forward
Closed : Reverse
12
Open: Stop (disable)
Closed: Run (enable)
Open : Preset speed 1
Closed : Digital (Keypad) Speed ref
External trip input :
Open: Trip,
Closed: No Trip
Open : Forward
Closed : Reverse
15
Open: Stop (disable)
Closed: Run (enable)
Open : Digital speed ref
Closed : Preset speed 1
Open: Decel Ramp 1 (P1-04)
Closed: Decel Ramp 2 (P2-25)
Open : Forward
Closed : Reverse
17
Open: Stop (disable)
Closed: Run (enable)
Open : Digital speed ref
Closed : Bipolar analog speed ref
Open : Digital / Analog ref
Closed : Preset speed 1
Bipolar analog input
18
Open: Stop (disable)
Closed: Run (enable)
Open : Digital speed ref
Closed : Preset speed ref
Digital Input 3
Bipolar analog input
Preset reference
Open
Open
Preset Speed 1
Closed
Open
Preset Speed 2
Open
Closed
Preset Speed 3
Closed
Closed
Preset Speed 4
19
Open: Stop (disable)
Closed: Run (enable)
Open : Digital speed ref
Closed : Analog input 2 ref
Analog input 2
Open : Forward
Closed : Reverse
20, 21
Open: Stop (disable)
Closed: Run (enable)
Digital Output :
Drive Healthy = +24V
Open : Digital speed ref
Closed : Preset speed 1
Open : Forward
Closed : Reverse
22
Open: Stop (disable)
Closed: Run (enable)
Digital Output :
Drive Healthy = +24V
External trip input :
Open: Trip,
Closed: No Trip
Open : Forward
Closed : Reverse
23
Open: Stop (disable)
Closed: Run (enable)
Open : Normal Operation
Closed : Fire Mode
Open: Digital speed ref
Closed: Preset speed 1
Open : Forward
Closed : Reverse
NOTE
By default, if the enable signal is present the drive will not Enable until the button is pressed. To automatically enable the
drive when the enable signal is present set P2-19 = 2 or 3. This then disables the use of the & STOP buttons
In keypad mode, the speed can be adjusted using the & keys on the built in keypad, or a remote mounted Optiport Plus
keypad, in addition to pushbuttons connected to the digital inputs
The reverse input only functions under the following conditions :-
P1-12 = 1, P2-19 = 2 or 3. P2-35 must not be 2 or 3
P1-12 = 2. P 2-35 must not be 2 or 3
The external trip input can be used to connect a motor thermistor by connecting between terminals 1 and 4
When P1-12 =2, the direction of motor can be reversed by
pressing the button
Closing the reverse input (When using a setting of P2-01 that inlcuides this function)
Using a negative speed reference (e.g. select a preset speed of -10Hz)
Since all of these functions can be active at once, care must be taken to ensure the motor always turns in the correct direction.
