480-525V ±10% - 3 Phase Input
3 Phase Output
Model
(kW)
kW
Model
(HP)
HP
Frame
Size
Nominal
Input
Current
Fuse or
MCB
(type B)
Supply
Cable Size
Nominal
Output
Current
110%
Output
Current 60
secs
Motor
Cable
Size
Max
Motor
Cable
Length
Min
Brake
Res
Value
Amps
Amps
mm
2
Amps
Amps
mm
2
m
Ω
ODV-55550
55
N/A
75
5
92.3
100
35
90
99
25
100
6
ODV-55750
75
100
5
116.9
125
50
110
121
35
100
6
ODV-55900
90
120
5
150.2
160
70
150
165
55
100
6
ODV-65132
132
175
6
217.2
250
120
202
222.2
90
100
6
ODV-65160
160
210
6
255.7
315
120
240
265
120
100
6
ODV-65200
200
250
6
290
315
170
270
297
170
100
6
NOTE
480 – 525 volt rated units are NOT UL listed
500-600V ±10% - 3 Phase Input
3 Phase Output
Model
(kW)
kW
Model
(HP)
HP
Frame
Size
Nominal
Input
Current
Fuse or
MCB
(type B)
Supply
Cable Size
Nominal
Output
Current
110%
Output
Current 60
secs
Motor
Cable
Size
Max
Motor
Cable
Length
Min
Brake
Res
Value
Amps
Amps
mm
2
Amps
Amps
mm
2
m
Ω
ODV-25150
1.5
ODV-25020-USA
2
2
4.1
6
1
3.1
3.4
1
100
47
ODV-25220
2.2
ODV-25030-USA
3
2
5.4
6
1
4.1
4.5
1
100
47
ODV-25370
3.7
ODV-25050-USA
5
2
7.6
10
1.5
6.1
6.7
1.5
100
47
ODV-25550
5.5
ODV-25075-USA
7.5
2
11.7
16
2.5
9
9.9
2.5
100
47
ODV-35075
7.5
ODV-35100-USA
10
3
16.1
20
2.5
14
15.4
2.5
100
22
ODV-35110
11
ODV-35150-USA
15
3
17.3
20
4
18
19.8
2.5
100
22
ODV-35150
15
ODV-35200-USA
20
3
24.1
25
4
24
26.4
4
100
22
ODV-45220
22
ODV-45300-USA
30
4
46.6
50
10
39
42.9
10
100
12
ODV-45300
30
ODV-45400-USA
40
4
54.1
63
16
46
50.6
10
100
12
ODV-45450
45
ODV-45600-USA
60
4
69.6
80
25
62
68.2
16
100
12
NOTE
For cUL compliance, fuse type Bussmann KTN-R / KTS-R or equivalent must be used
An external input choke must be fitted for all Frame Size 2 units
9.3. Maximum supply ratings for UL compliance:
Drive rating
Maximum supply voltage
Maximum supply
short-circuit current
230V ratings
0.37kW (0.5HP) to 18.5kW (25HP)
240V rms (AC)
5kA rms (AC)
230V ratings
22kW (30HP) to 90kW (120HP)
240V rms (AC)
10kA rms (AC)
400/460V/600V ratings
0.75kW (1.0HP) to 37kW (50HP)
500V/600V rms (AC)
5kA rms (AC)
400/460V/600V ratings
45kW (60HP) to 132kW (175HP)
500V/600V rms (AC)
10kA rms (AC)
400/460V/600V ratings
160kW (210HP)
500V/600V rms (AC)
18kA rms (AC)
All the drives in the above table are suitable for use on a circuit capable of delivering not more than the above specified maximum short-circuit
Amperes symmetrical with the specified maximum supply voltage.
