Optidrive VTC – User Guide
26 www.invertek.co.uk
9. Technical data
9.1. Environmental
Operational ambient temperature range: -10 … 50°C, Frost and condensation free
Storage ambient temperature range: -40 … 60°C
Maximum altitude: 2000m. Derate above 1000m : 1% / 100m
Maximum humidity: 95%, non-condensing
9.2. Rating tables
200-240V ±10% - 1 Phase Input
3 Phase Output
Model
(kW)
kW
Model
(HP)
HP
Frame
Size
Nominal
Input
Current
Fuse or
MCB
(type B)
Supply
Cable
Size
Nominal
Output
Current
110%
Output
Current
60 secs
Motor
Cable
Size
Max
Motor
Cable
Length
Min
Brake
Res
Value
Amps
Amps
mm
2
Amps
Amps
mm
2
m
Ω
ODV-22150
1.5
ODV-22020-USA
2
2
19.3
20
4
7
7.7
1.5
100
33
ODV-22220
2.2
ODV-22030-USA
3
2
28.8
32
6
10.5 (9)
11.6 (9.9)
1.5
100
22
NOTE
For cUL compliance, fuse type Bussmann KTN-R / KTS-R or equivalent must be used
200-240V ±10% - 3 Phase Input drive model set for 1 Phase Operation (See section 5.8)
3 Phase Output
Model
kW
Model
HP
Frame
Size
Nominal
Input
Current
Fuse or
MCB
(type B)
Supply
Cable Size
Nominal
Output
Current
110% Output
Current 60
secs
Motor
Cable Size
Max Motor
Cable
Length
Min
Brake
Res
Value
Amps
Amps
mm
2
Amps
Amps
mm
2
m
Ω
ODV-32030
1.5
ODV-32040-USA
2
3
19.3
20
4
7
7.7
1.5
100
15
ODV-32040
2.2
ODV-32050-USA
3
3
28.8
35
6
9
9.9
1.5
100
15
ODV-32055
3
ODV-32075-USA
4
3
31.3
35
6
12.5 (12)
13.8 (13.2)
2.5
100
15
ODV-42075
4
ODV-42100-USA
5
4
58.3
50
10
19.5
21.5
2.5
100
6
ODV-42110
5.5
ODV-42150-USA
7.5
4
67.6
80
16
23
25.3
4
100
6
ODV-42150
7.5
ODV-42200-USA
10
4
87.0
100
25
30.5
33.6
10
100
6
ODV-42185
9
ODV-42250-USA
12
4
96.1
100
25
36
39.6
10
100
6
ODV-42220
11
ODV-42300-USA
15
4
115.4
125
35
45
49.5
16
100
6
ODV-52300
15
ODV-52400-USA
20
5
146.1
160
50
55
60.5
16
100
3
ODV-52370
18.5
ODV-52500-USA
25
5
187.8
200
70
75
82.5
25
100
3
ODV-52450
22
ODV-52600-USA
30
5
220.6
250
90
90
99
25
100
3
NOTE
Values shown in brackets are the maximum for UL applications
For cUL compliance, fuse type Bussmann KTN-R / KTS-R or equivalent must be used
200-240V ±10% - 3 Phase Input
3 Phase Output
Model
kW
Model
HP
Frame
Size
Nominal
Input
Current
Fuse or
MCB
(type B)
Supply
Cable Size
Nominal
Output
Current
110% Output
Current 60
secs
Motor
Cable Size
Max Motor
Cable
Length
Min
Brake
Res
Value
Amps
Amps
mm
2
Amps
Amps
mm
2
m
Ω
ODV3-22150
1.5
ODV3-22020-USA
2
2
9.2
10
2.5
7
7.7
1.5
100
33
ODV3-22220
2.2
ODV-22030-USA
3
2
13.7
16
4
10.5 (9)
11.6 (9.9)
1.5
100
22
ODV-32030
3
ODV-32040-USA
4
3
16.1
20
4
14
15.4
1.5
100
15
ODV-32040
4
ODV-32050-USA
5
3
17.3
20
6
18
19.8
1.5
100
15
ODV-32055
5.5
ODV-32075-USA
7.5
3
25
25
6
25 (24)
27.5 (26.4)
2.5
100
15
ODV-42075
7.5
ODV-42100-USA
10
4
46.6
50
10
39
42.9
2.5
100
6
ODV-42110
11
ODV-42150-USA
15
4
54.1
63
16
46
50.6
4
100
6
ODV-42150
15
ODV-42200-USA
20
4
69.6
80
25
61
67.1
10
100
6
ODV-42185
18.5
ODV-42250-USA
25
4
76.9
80
25
72
79.2
10
100
6
ODV-42220
22
ODV-42300-USA
30
4
92.3
100
35
90
99
16
100
6
ODV-52300
30
ODV-52400-USA
40
5
116.9
125
50
110
121
16
100
3
ODV-52370
37
ODV-52500-USA
50
5
150.2
160
70
150
165
25
100
3
ODV-52450
45
ODV-52600-USA
60
5
176.5
200
90
180
198
25
100
3
NOTE
Values shown in brackets are the maximum for UL applications
For cUL compliance, fuse type Bussmann KTN-R / KTS-R or equivalent must be used
