INVT BD Series User Manual

8.LCD Operation
1. LCD Interface
1. PV1 input display interface
Interface
PV1 INPUT
VOLT: 33.8V
PV 1 input real-time voltage
CURR: 0.00A
PV 1 input real-time current
POWER: 0W
PV 1 input real-time power
8.1.2 PV2 input display interface
8.1.3 Bus voltage
8.1.4 Battery
8.1.5 BMS parameters
8.1.6 BMS parameters
8.1.7 Grid-connected output
8.1.8 Inverter output
Interface
PV1 INPUT
VOLT: 33.8V
PV 1 input real-time voltage
CURR: 0.00A
PV 1 input real-time current
POWER: 0W
PV 1 input real-time power
Interface
DC VOLTAGE
BUS: 33.8V
Real-time voltage of bus capacitor of the
machine
Interface
BATT ERY
VOLT: 48.9V
CURR: 0.00A
Real-time voltage of battery
Real-time battery current("+"means charge)
Interface
BATTERY INFOR
TYPE:LEAD-ACID
Battery type:(lead acid, lithium battery)
TEMP: 0.0℃
Battery temperature
SOC : 60%
Percentage of battery surplus capacity
Interface
BMS PRM ETER
The following parameters correspond to the set
values
CHAR VOLT: 54.5V
Battery charging voltage
CHARGE: 25A
Battery charging current
DISCHA:
100A
Battery discharging current
Interface
GRID OUTPUT
VOLT : 0.0V
Grid real-time voltage
CURR : 0.00A
CT real-time current
FREQ : 0.00Hz
Grid real-time frequency
Interface
INV OUTPUT
VOLT : 0.0V
Inverter real-time voltage
CURR : 0.00A
Inverter real-time current
FREQ : 0.00Hz
Inverter real-time frequency
44 45
LCD Operation LCD Operation
