INVT CHE100-0R4G-S2 User Manual

List of Function Parameters
94
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
P7.06
Running status
display selection
0~0X7FFF
BIT0: Output frequency
BIT1: Reference frequency
BIT2: DC bus voltage
BIT3: Output voltage
BIT4: Output current
BIT5: Rotation speed
BIT6: Output power
BIT7: Output torque
BIT8: PID preset
BIT9: PID feedback
BIT10: Input terminal status
BIT11: Output terminal status
BIT12: AI1
BIT13: AI2
BIT14: Step No. of multi-step
BIT15: Reserved
0XFF O 83
P7.07
Stop status display
selection
0~0X1FF
BIT0: Reference frequency
BIT1: DC bus voltage
BIT2: Input terminal status
BIT3: Output terminal status
BIT4: PID preset
BIT5: PID feedback
BIT6: AI1
BIT7: AI2
BIT8: Step No. of multi-step
BIT9~15: Reserved
0xFF O 84
P7.08
Rectifier module
temperature
0~100.0℃
● 85
P7.09
IGBT module
temperature
0~100.0℃
● 86
P7.10
Software version
● 87
P7.11
Accumulated running
time
0~65535h
● 88
