List of Function Parameters
100
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
PD.02
Amplitude of
restraining oscillation
0~10000
5000 O 151
PD.03
Boundary of
restraining oscillation
0.0~P0.04
12.5Hz O 152
PD.04
Restrain oscillation
0: Enabled
1: Disabled
0 O 153
PD.05
PWM mode
0: PWM mode 1
1: PWM mode 2
2: PWM mode 3
0

154
PD.06
Torque setting
source
0: Keypad
1: AI1
2: AI2
3: AI1+AI2
4: Multi-step setting
5: Communication
0 O 155
PD.07
Keypad torque
setting
-100.0%~100.0%
0 O 156
PD.08
Upper frequency limit
selection
0: Keypad (P0.05)
1: AI1
2: AI2
3: Multi-step setting
4: Communication
0 O 157
PD.09
Auto current limiting
selection
0: Enabled
1: Disabled when constant speed
0 O 158
PE Group: Factory Setting
PE.00 Factory password 0~65535 ***** ● 159
Special parameter for CHE150 series high speed inverter is as follow:
Function
Code
Name Description
Factory
Setting
Modify
P0 Group: Basic Function
P0.04 Maximum frequency 10.00~1500.0Hz 1000.0Hz

P0.05
Upper frequency limit P0.06~ P0.04
1000.0Hz O
P0.07
Keypad reference
frequency
0.00 Hz ~ P0.04
1000.0Hz O
P4 Group: V/F Control
