List of Function Parameters
99
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
8: ASCII, 1 start bit, 7 data bits, odd parity
check, 1 stop bit.
9: ASCII, 1 start bit, 7 data bits, no parity
check, 2 stop bits.
10: ASCII, 1 start bit, 7 data bits, even parity
check, 2 stop bits.
11: ASCII, 1 start bit, 7 data bits, odd parity
check, 2 stop bits.
12: ASCII, 1 start bit, 8 data bits, no parity
check, 1 stop bit.
13: ASCII, 1 start bit, 8 data bits, even parity
check, 1 stop bit.
14: ASCII, 1 start bit, 8 data bits, odd parity
check, 1 stop bit.
15: ASCII, 1 start bit, 8 data bits, no parity
check, 2 stop bits.
16: ASCII, 1 start bit, 8 data bits, even parity
check, 2 stop bits.
17: ASCII, 1 start bit, 8 data bits, odd parity
check, 2 stop bits.
PC.03
Communication
delay time
0~200ms
5 O 145
PC.04
Communication
timeout delay
0.0: Disabled
0.1~100.0s
0.0s O 146
PC.05
Communication error
action
0: Alarm and coast to stop
1: No alarm and continue to run
2: No alarm but stop according to P1.05 (if
P0.01=2)
3: No alarm but stop according to P1.05
1 O 147
PC.06
Response action
Unit’s place of LED
0: Response to writing
1: No response to writing
Ten’s place of LED
0: Reference not saved when power off
1: Reference saved when power off
0 O 148
PD Group: Supplementary Function
PD.00
Low-frequency
threshold of
restraining oscillation
0~500
5 O 149
PD.01
High-frequency
threshold of
restraining oscillation
0~500
100 O 150
