INVT CHE100-0R4G-S2 User Manual

List of Function Parameters
98
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
PB.00
Motor overload
protection
0: Disabled
1: Normal motor
2: Variable frequency motor
2

134
PB.01
Motor overload
protection current
20.0%~120.0%
100.0% O 135
PB.02
Threshold of trip-free 70.0~110.0%
80.0% O 136
PB.03
Decrease rate of
trip-free
0.00Hz~P0.04
0.00Hz O 137
PB.04
Over-voltage stall
protection
0: Disabled
1: Enabled
0 O 138
PB.05
Over-voltage stall
protection point
110~150%
Depend
on model
O 139
PB.06
Auto current limiting
threshold
50~200%
G:160%
P:120%
O 140
PB.07
Frequency decrease
rate when current
limiting
0.00~100.00Hz/s
10.00
Hz/s
O 141
PC Group: Serial Communication
PC.00 Local address 0~247
1 O 142
PC.01
Baud rate selection
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
4 O 143
PC.02 Data format
0: RTU, 1 start bit, 8 data bits, no parity
check, 1 stop bit.
1: RTU, 1 start bit, 8 data bits, even parity
check, 1 stop bit.
2: RTU, 1 start bit, 8 data bits, odd parity
check, 1 stop bit.
3: RTU, 1 start bit, 8 data bits, no parity
check, 2 stop bits.
4: RTU, 1 start bit, 8 data bits, even parity
check, 2 stop bits.
5: RTU, 1 start bit, 8 data bits, odd parity
check, 2 stop bits.
6: ASCII, 1 start bit, 7 data bits, no parity
check, 1 stop bit.
7: ASCII, 1 start bit, 7 data bits, even parity
check, 1 stop bit.
0 O 144
