INVT CHE100-0R4G-S2 User Manual

List of Function Parameters
92
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
P5.05
FWD/REV control
mode
0: 2-wire control mode 1
1: 2-wire control mode 2
2: 3-wire control mode 1
3: 3-wire control mode 2
0

58
P5.06
UP/DOWN setting
change rate
0.01~50.00Hz/s
0.50
Hz/s
O 59
P5.07
AI1 lower limit 0.00V~10.00V
0.00V O 60
P5.08
AI1 lower limit
corresponding
setting
-100.0%~100.0%
0.0% O 61
P5.09
AI1 upper limit 0.00V~10.00V
10.00V O 62
P5.10
AI1 upper limit
corresponding
setting
-100.0%~100.0%
100.0% O 63
P5.11
AI1 filter time
constant
0.00s~10.00s
0.10s O 64
P5.12
AI2 lower limit 0.00V~10.00V
0.00V O 65
P5.13
AI2 lower limit
corresponding
setting
-100.0%~100.0%
0.0% O 66
P5.14
AI2 upper limit 0.00V~10.00V
10.00V O 67
P5.15
AI2 upper limit
corresponding
setting
-100.0%~100.0%
100.0% O 68
P5.16
AI2 filter time
constant
0.00s~10.00s
0.10s O 69
P6 Group: Output Terminals
P6.00 Y output selection 1 O 70
P6.01
Relay output
selection
0: No output
1: Run forward
2: Run reverse
3: Fault output
4: FDT reached
5: Frequency reached
6: Zero speed running
7: Upper frequency limit reached
8: Lower frequency limit reached
9~10: reserved
3 O 71
