INVT CHE100-0R7G-S2 User Manual

List of Function Parameters
97
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
P9.00
PID preset source
selection
0: Keypad
1: AI1
2: AI2
3: Communication
4: Multi-step
0 O 115
P9.01
Keypad PID preset 0.0%~100.0%
0.0% O 116
P9.02
PID feedback source
selection
0: AI1
1: AI2
2: AI1+AI2
3: Communication
0 O 117
P9.03
PID output
characteristics
0: Positive
1: Negative
0 O 118
P9.04
Proportional gain
(Kp)
0.00~100.00
1.00 O 119
P9.05
Integral time (Ti) 0.01~10.00s
0.10s O 120
P9.06
Differential time (Td) 0.00~10.00s
0.00s O 121
P9.07
Sampling cycle (T) 0.01~100.00s
0.10s O 122
P9.08
Bias limit 0.0~100.0%
0.0% O 123
P9.09
Feedback lost
detecting value
0.0~100.0%
0.0% O 124
P9.10
Feedback lost
detecting time
0.0~3600.0s
1.0s O 125
PA Group: Multi-step Speed Control
PA.00
Multi-step speed 0
-100.0~100.0% 0.0% O 126
PA.01
Multi-step speed 1
-100.0~100.0% 0.0% O 127
PA.02
Multi-step speed 2
-100.0~100.0% 0.0% O 128
PA.03
Multi-step speed 3
-100.0~100.0% 0.0% O 129
PA.04
Multi-step speed 4
-100.0~100.0% 0.0% O 130
PA.05
Multi-step speed 5
-100.0~100.0% 0.0% O 131
PA.06
Multi-step speed 6
-100.0~100.0% 0.0% O 132
PA.07
Multi-step speed 7
-100.0~100.0% 0.0% O 133
PB Group: Protection Function
