INVT CHE100-0R7G-S2 User Manual

Detailed Function Description
61
1: Local and external keypad display simultaneously, only the key of external keypad is
valid.
2: Local and external keypad display simultaneously, only the key of local keypad is valid.
3: Local and external keypad display simultaneously, both keys of local and external
keypad are valid. Notice: This function should be used cautiously, otherwise it may
cause malfunction.
Notice:
 When P7.05 is set to be 1, local keypad is valid if external keypad is not
connected.
 When LCD keypad is connected, P7.05 must be set to be 0.
Function
Code
Name Description Setting Range
Factory
Setting
P7.06
Running status
display selection
0~0x7FFF 0~0x7FFF 0xFF
P7.06 defines the parameters that can be displayed by LED in running status. If Bit is 0,
the parameter will not be displayed; If Bit is 1, the parameter will be displayed. Press 》
/SHIFT to scroll through these parameters in right order . Press DATA/ENT +
QUICK/JOG to scroll through these parameters in left order.
The display content corresponding to each bit of P7.06 is described in the following table:
BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
Output
torque
Output
power
Rotation
speed
Output
current
Output
voltage
DC bus
voltage
Reference
frequency
Output
frequency
BIT15 BIT14 BIT13 BIT12 BIT11 BIT10 BIT9 BIT8
Reserved
Step No. of
multi-step
AI2 AI1
Output
terminal
status
Input
terminal
status
PID
feedback
PID
preset
For example, if user wants to display output voltage, DC bus voltage, Reference
frequency, Output frequency, Output terminal status, the value of each bit is as the
following table:
BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
0 0 0 0 1 1 1 1
BIT15 BIT14 BIT13 BIT12 BIT11 BIT10 BIT9 BIT8
