List of Function Parameters
89
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
P0.13
Restore parameters
0: No action
1: Restore factory setting
2: Clear fault records
0

13
P0.14 AVR function
0: Disabled
1: Enabled all the time
2: Disabled during deceleration
2 O 14
P1 Group: Start and Stop Control
P1.00
Start Mode
0: Start directly
1: DC braking and start
0

15
P1.01
Starting frequency 0.00~10.00Hz
1.5Hz O 16
P1.02
Hold time of starting
frequency
0.0~50.0s
0.0s O 17
P1.03
DC Braking
current before start
0.0~150.0%
0.0% O 18
P1.04
DC Braking time
before start
0.0~50.0s
0.0s O 19
P1.05
Stop mode
0: Deceleration to stop
1: Coast to stop
0 O 20
P1.06
Starting frequency of
DC braking
0.00~P0.04
0.00Hz O 21
P1.07
Waiting time before
DC braking
0.0~50.0s
0.0s O 22
P1.08
DC braking current 0.0~150.0%
0.0% O 23
P1.09
DC braking time 0.0~50.0s
0.0s O 24
P1.10
Dead time of
FWD/REV
0.0~3600.0s
0.0s O 25
P1.11
FWD/REV enable
when power on
0: Disabled
1: Enabled
0~1 O 26
P1.12 Reserved 0

27
P2 Group: Motor Parameters
P2.00
G/P option
0: G model
1: P model
Depend
on model

28
P2.01
Motor rated power 0.4~900.0kW
Depend
on model

29
