INVT GD100 User Manual

PRODUCT SPECIFICATIONS
Model SS2 S2 -2 -4
AC input voltage (V) 220(-15%) ~240(+10%) (1PH)
220(-15%)
~240 (+10%)
(3PH)
380(-15%)
~440 (=10%)
(3PH)
380(-15%)
~440 (=10%)
(3PH)
Max. DC input voltage (V)
440 440 440 800 900
Start-up voltage (V)
200 200 200 300 300
Lowest working voltage (V)
150 150 150 250 250
Recommended Dc input voltage range (V)
200 - 400 200 - 400 200 - 400 300 - 750 300 - 850
Recommended MPP voltage (V)
330 330 330 550 550
Rated output voltage (V)
220 (1PH) 220 (3PH) 220 (3PH) 380 (3PH) 380 (3PH)
Output frequency range (Hz) 0-400
MPPT 99%
Installation method wall mounting/rail mounting/flange installation
Environment parameters 10°C ~+50°C. If above 40°C, derate 2% for every additional 1°C
Altitude below 1000M. If above 1000M, derate 1% every additional 100M
Cooling manner fan cooling
Protection level
IP20 ; IP54 (cabinet)
Series Model
Rated output power
Rated input current (A)
Rated output current
(A)
KW HP
1 PH 220 input
GD 100-0R4G-SS2-PV
0.4 0.5 6.5 4.2
GD 100-0R7G-SS2-PV
0.75 1 9.3 7.2
1 PH 220V output
GD 100-1R5G-SS2-PV
1.5 2 15.7 10.2
GD 100-2R2G-SS2-PV
2.2 3 24 14
1 PH 220V
GD 100-0R4G-S2-PV
0.4 0.5 6.5 2.5
GD 100-0R7G-S2-PV
0.75 1 9.3 4.2
GD 100-1R5G-S2-PV
1.5 2 15.7 7.5
GD 100-2R2G-S2-PV
2.2 3 24 10
3 PH 220V
GD 100-1R5G-2-PV
1.5 2 7.7 7.5
GD 100-2R2G-2-PV
2.2 3 12 10
GD 100-004G-2-PV
4 5.5 17 16
GD 100-5R5G-2-PV
5.5 7.5 25 20
GD 100-7R5G-2-PV
7.5 10 33 30
3 PH 380V
GD 100-0R7G-4-PV
0.75 1 3.4 2.5
GD 100-1R5G-4-PV
1.5 2 5 4.2
GD 100-2R2G-4-PV
2.2 3 5.8 5.5
GD 100-004G-4-PV
4 5.5 13.5 9.5
GD 100-5R5G-4-PV
5.5 7.5 19.5 14
GD 100-7R5G-4-PV
7.5 10 25 18.5
GD 100-011G-4-PV
11 15 32 25
GD 100-015G-4-PV
15 20 40 32
GD 100-018G-4-PV
18.5 25 47 38
GD 100-022G-4-PV
22 30 56 45
GD 100-030G-4-PV
30 41 70 60
GD 100-037G-4-PV
37 50 80 75
GD 100-045G-4-PV
45 61 90 92
GD 100-055G-4-PV
55 73 105 115
GD 100-075G-4-PV
75 100 139 150
GD 100-090G-4-PV
90 120 168 180
GD 100-110G-4-PV
110 147 201 215
GD 100-132G-4-PV
132 177 265 260
GD 100-160G-4-PV
160 214 310 305
GD 100-185G-4-PV
185 248 345 340
GD 100-200G-4-PV
200 268 385 380
GD 100-220G-4-PV
220 299 430 425
GD 100-250G-4-PV
250 340 485 480
GD 100-280G-4-PV
280
381 545 530
GD 100-315G-4-PV
315 428 610 600
GD 100-355G-4-PV
355 482 625 650
GD 100-400G-4-PV
400 544 715 720
GD 100-450G-4-PV
450 612 840 820
GD 100-500G-4-PV
500 680 890 860

INVT GD100 Specifications

General

Control Mode	Torque Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5% to 95% (non-condensing)
Altitude	0~1000m (Derating above 1000m)
