INVT GD100 User Manual

BASIC SETUP SHEET FOR GD100
GROUP 0
BASIC FUNTION GROUP
00.01
1
Terminal Run Command
00.03
50
Maximum Running Frequency
00.04
50
Upper Freq Limit
00.05
35
Minimum Running Frequency
00.11
1.5
Acceleration time
1.5 Borehole 20 Centrifugal
00.12
20
Deceleration time
15 Borehole 20 Centrifugal
00.13
0/1
Running direction
GROUP 1 START UP AND STOP CONTROL
1.08
0 Stop mode Controlled stop (0) Coast to stop (1)
01.18
1 Operation protection
01.21
1 Restart after power of
GROUP 2 MOTOR 1 PARAMMETER
02.00 Motor type
0=3PH Motor, 1=1PH Motor
02.01 Rated of Power (kW)
TO BE OBTAINED FROM MOTOR
02.02
50
Rated of Freq (Hz)
02.03 Rated of Speed (RPM)
TO BE OBTAINED FROM MOTOR
02.04 Rated of Voltage (V)
TO BE OBTAINED FROM MOTOR
02.05 Rated Current (A)
TO BE OBTAINED FROM MOTOR
GROUP 5
Input terminals
05.01
1 S1 Terminals function selection
Fw Run
05.02
44
S2 Terminals function selection
44 = Low Level Probes 0 = No Function
05.03
0
S3 Terminals function selection
05.04
0
S4 Terminals function selection
05.05
0
S5 Terminals function selection
05.10
2
HDI Terminals Function
S3 Invert polarity
GROUP 8
ENHANCED FUNCTIONS
08.28
8
Nr. Fault Reset Times
08.29
1000
Fault reset seconds
GROUP 15
GROUP SPECIAL FUNCTION PARAMETERS FOR PV INVERTER
15.00
1 PV inverter selection
15.01
1 Vmpp Voltage reference
15.05
70%
Lower freq limit %
See setting below
15.16
5
Delay off tank low
15.17
600
Tank low wat up time
15.23
30
Delay time weak light
15.24
1200
Wate up wark light
Setting
15.05 = P00.05 / P00.03*100
All setting in yellow to be set
NB: Pump need to be off to set box
