Goodrive170-PV Series Solar Pump Inverter Function parameter list
-30-
Function
code
Name
Description
Default
Modify
38: Switch the running command channel to
communication
39: Reserved
40: Clear electricity consumption
41: Keep electricity consumption
42: Forcibly switches to power frequency
(Switching-on indicates switching to power
frequency, and switching-off indicates input
controlled by the keypad.)
43: Full-water signal
44: Empty-water signal
45: Two phase control mode of single-phase
motor
46: PV digital input without the boost module
(used for automatic switching)
47–63: Reserved
P05.10
Input
terminal
polarity
0x000–0x10F
BIT8
BIT2
BIT1
BIT0
HDI
S3
S2
S1
0x000
◎
P06 group Output terminals
Function
code
Name
Description
Default
Modify
P06.03
RO1 output
0: Disable
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: Inverter in fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Reserved
10: Upper limit frequency reached
11: Lower limit frequency reached
12: Ready for running
13: Reserved
30
○
P06.04
RO2 output
5
○
