Goodrive170-PV Series Solar Pump Inverter Fault diagnosis and solution
-53-
Fault
code
Fault type
Possible cause
Solution
EF
External fault
 SI external fault input
terminal action.
 Check the external device
input.
CE
RS485
communication
fault
 The baud rate setting is
incorrect.
 A fault occurs to the
communication wiring.
 The communication
address is incorrect.
 Communication suffers
from strong interference.
 Set a proper baud rate.
 Check the communication
interface wiring.
 Set a proper
communication address.
 Replace or change the
wiring to enhance the
anti-interference capacity.
ItE
Current detection
fault
 The control board
connector is in poor
contact.
 Hall device is damaged.
 An exception occurs on
the magnifying circuit.
 Check the connector and
re-plug.
 Replace the Hall device.
 Change the main control
board.
tE
Motor autotuning
fault
 The motor capacity does
not match the inverter
capacity.
 Motor parameters are not
set correctly.
 The difference between
the parameters obtained
from autotuning and the
standard parameters is
great.
 Autotuning timed out.
 Change the inverter model.
 Set the motor type and
nameplate parameters
correctly.
 Empty the motor load.
 Check the motor wiring and
parameter settings.
 Check whether the upper
limit frequency is higher
than 2/3 of the rated
frequency.
EEP
EEPROM
operation fault
 Error in reading or writing
control parameters.
 EEPROM is damaged.
 Press STOP/RST for reset.
Change the main control
board.
END
Running time
reached
 The actual running time
of the inverter is longer
than the internal set
running time.
 Ask the supplier to adjust
the preset running time.
OL3
Electronic overload
fault
 The inverter reports
overload pre-alarm
according to the setting.
 Check the load and
overload pre-alarm
threshold.
