INVT Goodrive200A Series User Manual

GD200A series VFD Function parameters
-64-
Function
code
Name
Description
Default
value
Modify
P06.01
Y1 output
0: Invalid
1: In operation
2: Forward rotation
3: Reverse rotation
4: Jogging
5: The VFD fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC step
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
20: External fault valid
22: Running time arrival
23: MODBUS communication virtual terminals output
26: DC bus voltage establishment
27: Auxiliary motor 1
28: Auxiliary motor 2
0
○
P06.02
HDO output
0
○
P06.03
Relay RO1
output
1
○
P06.04
Relay RO2
output
5
○
P06.05
Polarity
selection of
output
terminals
The function code is used to set the pole of the
output terminal.
When the current bit is set to 0, output terminal is
positive.
When the current bit is set to 1, output terminal is
negative.
BIT0
BIT1
BIT2
BIT3
Y
HDO
RO1
RO2
Setting range: 0–F
0
○
P06.06
Y1
switching-on
delay time
The function code defines the corresponding
delay time of the electrical level change during the
programmable terminal switching on and off.
0.000s
○
P06.07
Y1
switching-off
delay time
0.000s
○
