Besides P00.01 and P00.02, terminal command setting can also be used to set the running
command channel.
Current running
command
channel
P00.01
Multi-function
terminal 36
Shifting the
command to keypad
Multi-function
terminal 37
Shifting the
command to
communication
Multi-function terminal
38
Shifting the command
to communication
Keypad running
command channel
Terminal running
command channel
Communication running
command channel
Terminal running
command channel
Keypad running
command channel
Communication running
command channel
Communication
running command
channel
Keypad running
command channel
Terminal running
command channel
Note: "/" means the multi-function terminal is invalid on the current reference channel.
7.3 Vector control
Because asynchronous motors have the characteristics of high stage, nonlinear, strong coupling
and various variables, the actual control of the asynchronous motor is very difficult. Vector control is
mainly used to settle this problem with the theme of that divide the stator current vector into exciting
current (the current heft generating internal magnetic field of the motor) and torque current (the
current heft generating torque) by controlling and measuring the stator current vector according to
the principles of beamed magnetic field to control the range and phase of these two hefts. This
method can realize the decoupling of exciting current and torque current to adjust the high
performance of asynchronous motors.
Goodrive200A series VFDs are embedded speed sensor-less vector control calculation. Because
the core calculation of vector control is based on exact motor parameter models, the accuracy of
motor parameter will impact on the performance of vector control. It is recommended to input the
motor parameters and carry out autotune before vector running.
Because the vector control calculation is very complicated, high technical theory is needed for the
user during internal autotune. It is recommended to use the specific function parameters in vector
control with cautions.
