Goodrive350-19 series VFD Commissioning
- 94 -
Lifting motor
Ground
Upward limit
position
Downward
limit position
Rope
droop
length
P19.15
P93.11
P93.12
P93.09
Winding turns of outermost layer
P93.14
Full layer winding turns
P93.13
P93.15
Encoder
P93.17
P93.18
Figure 5.14 Internal measuring (motor encoder), without pulleys
