INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 103 -
Function
code
Name
Description
Setting
speeds and heights)
2: Enable external measuring (HDI)
(in open/closed-loop mode, the pulley encoder
measures heights)
Note: When P93.08=2 and P20.15=0, HDI is used
to measure heights.
P93.09
Mechanical
transmission ratio
0.01–300.00
1.00
P93.10
Suspension ratio
1–4
1
P93.11
Rope length
compensation
0.00m–50.00
0.00
P93.12
Cable diameter
0.1–100.0mm
10.0mm
P93.15
Pulley diameter
100.0–2000.0mm
600.0mm
Height status check
P93.17
Total height
measured
0.00–655.35m (Total height measured from the
upward limit position to the downward limit position)
0.00m
P93.18
Measured height 1
-50.00m–655.35m (Using the downward limit
position as the reference point)
0.00m
P19.15
Measured height
0.00–655.35m (Hook lowering distance)
0.00m
P19.16
MSB of measured
height
0–65535
0
P19.17
LSB of measured
height
0–65535
0
